The Innoweight 6 Digit 7 Segment Display is a high-quality, reliable, and easy-to-use display solution designed specifically for weighing scales. Featuring both 0.56-inch and 0.8-inch options, available in red and green, and a common anode configuration, this display is ideal for a wide range of industrial and commercial weighing applications. With a focus on precision, clarity, and energy efficiency, it stands out as an essential component for any modern weighing scale system.
Key Features:
1. 6-Digit 7-Segment Display
– The display features six digits, each formed by seven segments, allowing for clear and easy-to-read numerical outputs.
– This configuration makes it ideal for applications that require precise and clear weight measurements, ensuring operators can quickly interpret data.
2. Multiple Display Size Options
– Available in 0.56-inch and 0.8-inch digit sizes, users can choose the size that best suits their visibility needs. The larger size option is particularly beneficial for environments where the display needs to be seen from a distance.
3. Green and Red LED Colors
– Available in green and red LED colors, these displays provide flexibility depending on environmental conditions and user preferences. Green offers high clarity in well-lit environments, while red provides better visibility in low-light settings.
4. Common Anode Configuration
– The common anode configuration ensures compatibility with a wide range of circuit designs and microcontrollers, making it easier for engineers to integrate the display into their existing weighing systems.
5. Wide Voltage Range
– With a forward voltage range of 3.3 ~ 5VDC, this display can be used in various electrical setups, making it versatile and adaptable for different power supply configurations.
6. Low Operating Current
– The 20mA operating current ensures energy efficiency, which is particularly important in long-term applications where power conservation is a key concern. This feature also reduces the load on power supplies, contributing to the overall reliability of the system.
7. Compact and Lightweight Design
– The 25g weight, 36mm length, 100mm width, and 10mm height make this display incredibly compact and lightweight, facilitating easy integration into a range of devices and systems. Its slim profile allows it to fit into tight spaces without compromising on performance.
8. Pin Header Pitch of 2.54mm
– The 2.54mm pin header pitch offers easy compatibility with standard breadboards and PCBs, streamlining the process for users to integrate it into their weighing systems.
Benefits of the Innoweight 6 Digit 7 Segment Display:
1. Enhanced Visibility
– With its clear 7-segment configuration and options for green and red LED colors, this display ensures high visibility in all lighting conditions, minimizing the risk of operator error due to unreadable data.
2. Energy-Efficient Performance
– The low 20mA operating current reduces power consumption, making this display suitable for continuous operation in battery-operated and energy-conscious applications, thereby extending the life of the device.
3. Easy Integration
– The common anode configuration and 2.54mm pin header pitch make the display easy to integrate with a wide variety of microcontrollers, circuit boards, and other electrical systems, reducing setup time and complexity.
4. Flexibility for Different Applications
– The option to choose between 0.56-inch and 0.8-inch sizes allows users to select the right display for their specific use case, whether for handheld or large, industrial-scale weighing systems.
5. Compact and Lightweight Design
– Its compact design allows for flexible installation in confined spaces, making it perfect for small and large weighing machines alike.
6. Durability for Industrial Environments
– This display is built to withstand harsh environments typically found in industrial and commercial weighing applications, ensuring long-term reliability.
7. Customizable Display Options
– The dual-color LED options (red and green) allow users to customize the display based on the color scheme of their weighing systems or environmental needs.
Customer Pain Points Addressed:
1. Poor Display Visibility in Different Lighting Conditions
– The green and red LED options ensure maximum visibility, whether in bright environments or dark settings, preventing errors and improving operational efficiency.
2. Power Consumption Concerns
– The low 20mA current makes it an energy-efficient solution, reducing the risk of power drain and the need for frequent battery changes in weighing scales.
3. Difficulty in Integration with Existing Systems
– The common anode configuration and 2.54mm pin header pitch allow for easy integration with standard circuit designs and microcontrollers, minimizing setup time and complexity.
4. Limited Display Size Options
– The 0.56-inch and 0.8-inch display size options provide flexibility for different installation environments, whether for handheld weighing scales or larger industrial machines.
5. Limited Space for Installation
– The compact size (36mm x 100mm x 10mm) ensures that the display can be integrated into smaller weighing systems without compromising on performance.
Competitive Advantages Over Indian Market Competitors:
1. Customizable Size and Color Options
– Many competitors offer limited size or color choices for their displays. Innoweight’s offering of both 0.56-inch and 0.8-inch sizes, along with red and green LED color choices, gives customers greater flexibility and personalization options to meet their specific needs.
2. Low Power Consumption
– Innoweight’s 20mA operating current is relatively low compared to competitors, which often have higher power consumption displays. This makes the Innoweight display ideal for energy-conscious businesses looking to reduce operational costs.
3. Ease of Integration
– The common anode configuration and standard 2.54mm pitch make this display easier to integrate than many of its competitors, which may use non-standard configurations or require more complex wiring setups.
4. Durability in Harsh Environments
– The compact, lightweight design coupled with efficient LED performance means Innoweight’s displays can withstand industrial environments better than many lower-quality competitors, ensuring long-term reliability.
5. Wide Voltage Range Compatibility
– Innoweight’s ability to operate within a 3.3 ~ 5VDC range offers greater versatility compared to competitors that may be restricted to a specific voltage range.
External Educational Resources:
1. Understanding Seven-Segment Displays
– [Seven Segment Display – Wikipedia](https://en.wikipedia.org/wiki/Seven-segment_display): An overview of seven-segment displays and how they are used in electronic devices like weighing scales.
– [How to Choose a Seven-Segment Display](https://www.electronics-tutorials.ws/io/7-segment-display.html): This guide explains the different types of seven-segment displays and the factors to consider when selecting one for your application.
2. Benefits of Low Power Consumption in Displays
– [Power Consumption in LED Displays]: Learn more about the energy-saving benefits of low-current LED displays and how they impact long-term operations.
– [Why Low Power Displays Matter in Industrial Applications]: An article on the importance of power-efficient displays in reducing operational costs for industrial companies.
3. How to Integrate a 7-Segment Display into Your System
– [Integrating Displays with Microcontrollers]: A step-by-step guide on how to easily integrate seven-segment displays into electronic systems.
Conclusion
By focusing on energy efficiency, clear visibility, and ease of integration, the Innoweight 6 Digit 7 Segment Display stands out in the Indian market as an ideal solution for weighing scales in various industries, including manufacturing, retail, and logistics.
