Introduction
The Innoweight Single Point Loadcell for tabletop weighing scales is engineered for precision and reliability in a wide variety of industrial, commercial, and laboratory applications. With an impressive range of 6kg to 80kg, this loadcell is designed to provide unparalleled accuracy and durability, ensuring that your weighing equipment delivers consistent, high-quality performance. Constructed with anodized aluminum and equipped with IP65 water-resistant protection, it can withstand demanding environments where both precision and durability are essential.
—
Key Benefits
1. High Precision and Accuracy
– Benefit: The Innoweight Single Point Loadcell offers comprehensive precision with a tolerance range of 0.02~0.05% FS, ensuring high accuracy for tabletop weighing scales.
– Pain Point Addressed: Businesses that require accurate measurements in environments like laboratories, workshops, or production lines can trust this loadcell for consistent performance.
2. Wide Load Range (6kg to 80kg)
– Benefit: Available in capacities of 6kg, 10kg, 20kg, 40kg, and 80kg, this loadcell provides flexibility for various types of applications.
– Pain Point Addressed: Different businesses often require a loadcell that fits specific weight ranges, and the Innoweight loadcell meets these diverse needs without compromising accuracy.
3. Water Resistant (IP65 Protection)
– Benefit: With an IP65 rating, the loadcell is resistant to dust and water, making it ideal for use in wet or humid environments.
– Pain Point Addressed: In environments such as kitchens, factories, or outdoor settings, where moisture or dust can interfere with the functionality of weighing equipment, the Innoweight loadcell ensures reliability and performance.
4. Temperature Stability
– Benefit: It operates efficiently across a broad temperature range of -20°C to +65°C, with minimal temperature effects on both output and zero.
– Pain Point Addressed: In industries where temperature fluctuations are common, such as warehouses or outdoor storage, this loadcell ensures precise measurements regardless of external temperature changes.
5. Durable and Robust Construction (Anodized Aluminium)
– Benefit: The anodized aluminum body ensures enhanced durability, corrosion resistance, and long-lasting performance even in harsh conditions.
– Pain Point Addressed: Businesses can rely on the loadcell’s robust construction, which reduces maintenance costs and prolongs the lifespan of their weighing equipment.
6. Low Creep and High Sensitivity
– Benefit: With a creep of ±0.02% FS/30min and a sensitivity of 2.0 mV/V, this loadcell offers excellent responsiveness and stability.
– Pain Point Addressed: For customers who need precise, real-time measurements without drift or fluctuation, this loadcell ensures consistent performance over time.
7. High Safe Load Limit (150% FS)
– Benefit: The loadcell can safely handle up to 150% of its full scale capacity, which ensures it can withstand unexpected overloading without damage.
– Pain Point Addressed: In demanding industrial applications where overloading can occur, this high safe load limit ensures the equipment remains operational, reducing potential downtime and repair costs.
8. Easy Integration and Mounting
– Benefit: The cylindrical head screw mounting system (M6-8.8) and standard tightening torque (10 N.m) ensure simple and secure integration into weighing systems.
– Pain Point Addressed: Installation is straightforward, saving both time and effort in integrating the loadcell into existing setups.
9. Long-Term Reliability (Insulation Resistance >5000 MΩ)
– Benefit: The loadcell features a high insulation resistance of greater than 5000 MΩ, ensuring longevity and preventing electrical failures.
– Pain Point Addressed: Users who face issues with electrical interference or failure in other loadcells can rely on this product for a more durable and dependable solution.
—
Key Features
1. Capacity Range:
– Available in 6kg, 10kg, 20kg, 40kg, and 80kg capacities, allowing for use in a wide range of applications.
2. Precision:
– Comprehensive precision range of 0.02~0.05% FS, ensuring accurate measurements in all use cases.
3. Creep (±0.02% FS/30min):
– Minimizes drift over time, maintaining high accuracy.
4. Temperature Stability:
– ±0.02% FS/10℃ temperature effect on both zero and output, ensuring accuracy in varying environmental conditions.
5. Operating Temperature Range:
– The loadcell functions efficiently from -20°C to +65°C, making it suitable for a wide range of climates and environments.
6. Material:
– Constructed from anodized aluminum, providing a lightweight, corrosion-resistant, and durable build.
7. Protection Class:
– Rated IP65 for protection against water and dust, ensuring the loadcell can be used in wet or dusty environments without degradation.
8. Insulation Resistance:
– >5000 MΩ insulation resistance at 50Vdc, ensuring reliable electrical performance over time.
9. Hysteresis and Non-Linearity:
– Hysteresis error of ±0.02% and non-linearity of ±0.027% ensure precise readings, reducing measurement errors during usage.
10. Bridge Voltage:
– The loadcell operates with a reference bridge voltage of 10V DC, ensuring reliable power performance.
—
Addressing Customer Pain Points
– Precise Measurements: Customers in industries such as manufacturing, food production, or laboratory testing require highly accurate and consistent measurements. This loadcell provides the precision needed to meet those demands, preventing errors and improving product quality.
– Environmental Challenges: In many industries, environmental factors such as dust, moisture, or temperature fluctuations can affect the performance of loadcells. The Innoweight Single Point Loadcell addresses this issue with its IP65 rating and broad temperature range, ensuring reliable performance even in harsh conditions.
– Durability and Long-Term Use: Regular maintenance or frequent replacements can lead to increased operational costs. The anodized aluminum body, high safe load limit, and long-lasting durability ensure the loadcell remains operational for years, reducing the need for frequent repairs.
– Ease of Use: Installation and integration into existing weighing systems can be time-consuming and complex. The simple mounting system and ease of installation allow businesses to quickly deploy the loadcell without disrupting operations.
—
Competitive Advantages Over Indian Competitors
– Durability and Precision: While many local competitors offer similar loadcells, the Innoweight Single Point Loadcell stands out due to its combination of high precision (0.02~0.05% FS), robust anodized aluminum construction, and resistance to environmental factors such as moisture and temperature changes.
– Higher Safe Load Limit: At 150% FS, the Innoweight loadcell offers a higher safe load limit than many competing products in the market, making it more reliable for high-stress applications.
– Temperature and Creep Stability: Innoweight’s loadcell features minimal creep and highly stable output in varying temperatures, a key advantage for businesses that need reliable measurements over time and in fluctuating environments.
—
External Resources for Further Reading:
– [Understanding Loadcell Precision]
– [IP65 Protection Class Explained]
– [How Temperature Affects Loadcells]
—
This comprehensive breakdown of the Innoweight Single Point Loadcell for tabletop weighing scales highlights its exceptional accuracy, durability, and suitability for various industries. By addressing key customer pain points, such as environmental resistance, ease of installation, and long-term reliability, this loadcell sets itself apart from competitors in the Indian market, offering an ideal solution for businesses that demand precision and robustness in their weighing systems.
